Quo-Lab® HbA1c Analyzer

Product Overview

Quo-Lab® HbA1c is a semi-automated desktop point-of-care analyzer for measuring glycated hemoglobin (HbA1c).

The semi-automated analyzer has been designed specifically to meet the needs of diabetes clinics and laboratories in settings that demand a low cost of operation and ease of use.

From a simple procedure, Quo-Lab provides lab-accurate test results within four minutes (CV  3% at 7% A1c) from a venous or finger-prick blood sample of just 4 μl. Quo-Lab uses the same boronate affinity methodology used by Quo-Test® HbA1c and is similarly unaffected by Hb variants.

Step-by-step instructions are displayed on a clear, multi-lingual display. Staff training time can therefore be minimized and the opportunity for error is reduced.

Quo-Lab HbA1c can store over 7,000 results which can be downloaded as text files to a PC via the integrated USB interface. Alternatively, results can be printed using a printer that connects via a serial port.

Quo-Lab has received its CE mark and is available for sale in most global markets subject to local registration requirements.

Easy to use

• User-friendly features minimize training time
• Step by step instructions on the display
• User-selectable language
• Just 4 µl blood required from a finger prick or venous sample
• Innovative blood collector allows easy and consistent sampling
• Lightweight: 0.7 kg

Efficient data handling

• Barcode reader to scan calibration data, patient and operator ID
• Stores over 7,000 results
• User selectable dual reporting. User can select % DCCT, IFCC mmol/mol, eAG mg/dl or eAG mmol/l
• USB port
• Optional label printer available

Fast and accurate

• Results within four minutes
• Uses boronate affinity methodology which is widely recognized as interference-free
• Measuring range: 4-15 % A1c DCCT
• Imprecision: CV  3 % at 7 % A1c DCCT
• Unaffected by Hb variants, which do not result in reduced erythrocyte life span
• Traceable to the IFCC reference method
