– thermal resistance analysis of building materials
– electronic and electro-technical components
– tests of properties of products subjected to high temperatures
– drying of wires of papermaking machines
– drying of laboratory glass
– general aging and curing
– preheating
– digestion of proteins
– plant tissues drying
– drug metabolism
– paper drying
| TECHNICAL DATA | |
| air convection | natural |
| chamber capacity [l] | 75 |
| working capacity [l] | 75 |
| controller | microprocessor PID |
| display | 4,3" full color touch screen |
| TEMPERATURE | |
| temperature range [°C] | 5°C above ambient temperature … +300°C |
| temperature resolution every … [°C] | 0,1 |
| over-temperature protection | class 2.0 to DIN 12880 / class 3.1 (option) |
| CHAMBER | |
| door type | solid / door with viewing window (option) |
| interior | |
| Smart | acid-proof stainless steel to DIN 1.4301 |
| IG Smart | acid-proof stainless steel to DIN 1.4301 |
| housing | |
| Smart | powder-coated sheet |
| IG Smart | stainless steel linen finish |
| overall dims [mm] /1/ | |
| width A | 590 |
| height B | 850 |
| depth C | 620 |
| internal dims [mm] | |
| width D | 400 |
| height E | 530 |
| depth F | 360 |
